TP181A1-CR Current Sensing Amplifiers-3PEAK
文章出处:
人气:发表时间:2023-10-25 22:38
The TP181A1-CR series of zero-drift,bi-directional current sense amplifier can sense voltage drops across shunts at commonmode voltages from–0.3V to 36V,independent of the supply voltage.Three fixed gains are available:50V/V,100V/V and 200V/V.The low offset of the zero-drift architecture enables current sensing with maximum drops across the shunt as low as 10mV full-scale.
TP181A1-CR devices operate from a single+2.7V to 30V power supply,with drawing a typical of 120uA of supply current.All versions are specified from–40°C+125°C,and offered in SC70-6 packages.
TP181A1-CR Features:
-VOLTAGE OFFSET:±100uV(MAX)
-WIDE COMMON MODE VOLTAGE:-0.3V to+36V
-SUPPLY VOLTAGE:2.7V to+30V
-ACCURACY and ZERO-DRIFT PERFORMANCE
-±1%Gain Error(Max over temperature)
-0.5μV/°C Offset Drift(Max)
-10ppm/°C Gain Drift(Max)
-THREE GAIN OPTIONS for VOLTAGE OUTPUT
-TP181A1:50V/V
-TP181A2:100V/V
-TP181A3:200V/V
-LOW SUPPLY CURRENT:120uA(TYP)
-Rail-to-Rail Output
-PACKAGE:SC70-6
-Industrial–40°C to 125°C Operation Range
-ESD Rating:Robust 2KV–HBM,2KV–CDM
-Higher performance Drop-In Compatible With INA213,INA214,INA199,NCS199 Products
TP181A1-CR Applications:
-CURRENT SENSING(High−Side/Low−Side)
-BATTERY CHARGERS
-POWER MANAGEMENT
-CELL PHONE CHARGER
-ELECTRICAL CIGIRATE
-WIRELESS CHARGER
-TELECOM EQUIPMENT
